Creating a Python Config Object using AWS Secrets Manager

November 30, 2022

Stewart Moreland

Whether you're developing your application to use Lambda functions, ECS or EKS containers, SageMaker Notebooks, or EC2 instances, the proper configuration management can make all the difference in the world in developer ergonomics, application security, and secrets management.

In this guide, we'll walk through how to create a Python configuration class using AWS Secrets Manager and Python object inheritance. We'll also demonstrate the use of our configuration object using AWS Lambda functions and the AWS Serverless Application Model CLI.

Prerequisites

Before starting this guide, ensure you have:

An AWS Account
AWS CLI installed and configured
AWS SAM CLI installed
Docker Desktop
AWS Python SDK (Boto3)
Some experience with Python Development

Architecture

Guide

Create a Secret

In your AWS account, create a new secret in AWS Secrets Manager. We'll use a generic key/value secret for this example but any secret type could be applied so long as we use the proper Boto3 method to retrieve it.

Create Secret via AWS CLI

aws secretsmanager create-secret \
  --name hello-world/stage \
  --secret-string '{"DB_ENDPOINT": "mydb.example.com","DB_USERNAME": "mydbuser", "DB_PASSWORD": "supersecret"}'

This command creates a hello-world/stage secret and adds three key/value pairs for DB_ENDPOINT, DB_USERNAME, and DB_PASSWORD. Now that we have a secret created, let's create an app that uses it.

Generate a Serverless App

SAM CLI offers boilerplate templates so we can get started developing quickly. To begin, run the following command in your preferred terminal to create a basic hello-world serverless application with Lambda and API Gateway.

Initialize SAM Application

sam init --name sam-app --runtime python3.9 --app-template hello-world --no-tracing

Using this command, SAM CLI has created a new directory with the name of our application. In this case, sam-app. Open this directory in your favorite integrated development environment (IDE).

💡 Directory Structure

SAM CLI generates a structured project with separate directories for your Lambda functions, events for testing, and CloudFormation templates.

Project Structure

sam-app
│   __init__.py
│   .gitignore
│   README.md
│   template.yaml
│
└───events
│   │   event.json
│
└───hello_world
    │   __init__.py
    │   app.py
    │   requirements.txt

Configure CloudFormation Template

Start by opening template.yaml and add two new parameters directly under the template description.

template.yaml - Add Parameters

Parameters:
  Environment:
    Type: String
    Default: local
  SecretName:
    Type: String
    Default: ""

We'll use the Environment parameter to tell us which config class we want to implement, and the SecretName to define which AWS Secrets Manager secret we want to use to source our credentials.

Empty String Default

Notice how we've passed an empty string to the SecretName parameter. We do this so that when invoking the function locally, we don't pass a null value to the environment variable we create.

IAM Role Configuration

It's important for our function to have the appropriate IAM policy, granting it permission to use our newly created secret. Let's add the appropriate IAM role & policy as CloudFormation resources to the template.yaml.

yaml

LambdaIAMExecutionRole:
  Type: AWS::IAM::Role
  Properties:
    AssumeRolePolicyDocument:
      Version: "2012-10-17"
      Statement:
        - Effect: "Allow"
          Principal:
            Service: "lambda.amazonaws.com"
          Action: "sts:AssumeRole"
    Description: Lambda execution role for secrets access
    ManagedPolicyArns:
      - arn:aws:iam::aws:policy/service-role/AWSLambdaBasicExecutionRole

Update Lambda Function Configuration

With the new IAM role & policy resources, add a Role property to the HelloWorldFunction resource in our template.yaml.

Update Lambda Function Role

HelloWorldFunction:
  Type: AWS::Serverless::Function
  Properties:
    # ... existing properties
    Role: !GetAtt LambdaIAMExecutionRole.Arn
    Environment:
      Variables:
        ENVIRONMENT: !Ref Environment
        SECRET_NAME: !Ref SecretName

Also replace the Output value referencing the HelloWorldFunctionRole.Arn with LambdaIAMExecutionRole.Arn:

Update CloudFormation Outputs

Outputs:
  # ... other outputs
  HelloWorldFunctionIamRole:
    Description: "Implicit IAM Role created for Hello World function"
    Value: !GetAtt LambdaIAMExecutionRole.Arn

📊 Security Benefits

+100%

Automatic%

Secret Rotation

+95%

IAM-based%

Access Control

+100%

CloudTrail%

Audit Trail

Complete Template Configuration

Your final template.yaml file should look like this structure:

Complete template.yaml

AWSTemplateFormatVersion: '2010-09-09'
Transform: AWS::Serverless-2016-10-31
Description: >
  sam-app
  Sample SAM Template for sam-app with AWS Secrets Manager integration

Parameters:
  Environment:
    Type: String
    Default: local
  SecretName:
    Type: String
    Default: ""

Globals:
  Function:
    Timeout: 3

Resources:
  HelloWorldFunction:
    Type: AWS::Serverless::Function
    Properties:
      CodeUri: hello_world/
      Handler: app.lambda_handler
      Runtime: python3.9
      Role: !GetAtt LambdaIAMExecutionRole.Arn
      Architectures:
        - x86_64
      Environment:
        Variables:
          ENVIRONMENT: !Ref Environment
          SECRET_NAME: !Ref SecretName
      Events:
        HelloWorld:
          Type: Api
          Properties:
            Path: /hello
            Method: get

  LambdaIAMExecutionRole:
    Type: AWS::IAM::Role
    Properties:
      AssumeRolePolicyDocument:
        Version: "2012-10-17"
        Statement:
          - Effect: "Allow"
            Principal:
              Service: "lambda.amazonaws.com"
            Action: "sts:AssumeRole"
      ManagedPolicyArns:
        - arn:aws:iam::aws:policy/service-role/AWSLambdaBasicExecutionRole

  LambdaIAMExecutionRolePolicy:
    Type: AWS::IAM::Policy
    Properties:
      PolicyDocument:
        Version: "2012-10-17"
        Statement:
          - Action:
              - "secretsmanager:Get*"
              - "secretsmanager:List*"
              - "secretsmanager:Describe*"
            Effect: "Allow"
            Resource:
              - !Sub arn:aws:secretsmanager:${AWS::Region}:${AWS::AccountId}:secret:hello-world/stage*
      PolicyName: !Sub "sam-app-demo-execution-policy-${Environment}"
      Roles:
        - !Ref LambdaIAMExecutionRole

Outputs:
  HelloWorldApi:
    Description: "API Gateway endpoint URL for Prod stage for Hello World function"
    Value: !Sub "https://${ServerlessRestApi}.execute-api.${AWS::Region}.amazonaws.com/Prod/hello/"
  HelloWorldFunction:
    Description: "Hello World Lambda Function ARN"
    Value: !GetAtt HelloWorldFunction.Arn
  HelloWorldFunctionIamRole:
    Description: "Implicit IAM Role created for Hello World function"
    Value: !GetAtt LambdaIAMExecutionRole.Arn

Next Steps

In the next part of this series, we'll implement the Python configuration class that will read from AWS Secrets Manager and provide a clean interface for accessing configuration values in your Lambda functions.

Key Benefits of This Approach

💡 Security Best Practices

Centralized Secret Management: All secrets stored in AWS Secrets Manager
Automatic Rotation: Supports AWS automatic secret rotation
Fine-grained Access Control: IAM policies control access to specific secrets
Audit Trail: All secret access is logged in CloudTrail

This foundation sets up secure, scalable configuration management for your Python applications running on AWS infrastructure. The pattern works across Lambda, ECS, EKS, and EC2 deployments with minimal modifications.
